| Frame |
OCLV Mountain Carbon main frame, 1.8” lower head tube, Bosch System Controller compatible, Removable Integrated Battery (RIB), Knock Block 2.0, guided internal routing, 34.9mm seat tube, magnesium rocker link, Motor Armor, Mino Link, ABP, Boost148, 12mm thru axle, 150mm travel BB Standard: Bosch, Press Fit Tire Clearance: 2.6″ Colors: Deep Smoke; Lava; Satin Baja Yellow |
|---|---|
| Fork |
RockShox ZEB Select+, DebonAir spring, Charger 3 RC2 damper, 1.8” oversized tapered steerer, eMTB optimized crown, 44mm offset, Boost110, 15mm Maxle Stealth, 160mm travel |
| Rear Shock |
RockShox Super Deluxe Select+ RT, 230mm x 57.5mm |
| Bottom Bracket |
Bosch, press-fit |
| Stem |
Bontrager Line Pro, 35mm, Knock Block, Blendr compatible, 0 degree, 45mm length |
| Handlebar |
Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 780mm width |
| Saddle |
Bontrager Arvada, austenite rails, 138mm width |
| Seatpost |
Size: S, Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length; Size: M, Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 440mm length; Size: L, Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 485mm length; Size: XL, Bontrager Line Elite Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 550mm length |
| Grips |
Bontrager XR Trail Elite, nylon lock-on |
| Rear Derailleur |
Shimano XT M8100, long cage |
|---|---|
| Crank |
E*thirteen E*spec Plus, 165mm length |
| Shifters |
Shimano XT M8100, 12 speed |
| Cassette |
Shimano XT M8100, 10-51, 12 speed |
| Chain |
Shimano XT M8100, 12 speed |
| Brakes |
Shimano XT M8120 4-piston hydraulic disc |
| Rims |
Bontrager Line Comp 30, Tubeless Ready |
|---|---|
| Front Hub |
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
| Rear Hub |
Size: S, M, L, XL, Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12mm thru axle; Size: S, M, L, XL, Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle |
| Tires |
Size: S, M, L, XL, Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29×2.50”; Size: S, M, L, XL, Bontrager SE6 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29×2.50” |
| Disk Rotors |
Shimano RT76, 6-bolt, 203mm |
| Motor |
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm |
|---|---|
| Battery |
Size: S, Bosch PowerTube 625Wh, smart system; Size: M, L, XL, Bosch PowerTube 750Wh, smart system |
| Charger |
Bosch standard 4A, 110V, smart system |
