| Frame |
Epocalypse 166mm of travel, UD carbon, Full internal cable routing, SB+ 157mm rear spacing BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork |
Rockshox ZEB Ultimate, 29 |
| Rear Shock |
Rockshox Super Deluxe Coil Ultimate, Trunnion 205×65, ML 320 |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
Cane Creek 40 Series ZS Integrated Tapered Headset – Cups: ZS44/28.6 (Upper) and ZS62/40(Lower), Bearing: 36° x 45° – 41mm (Upper) and 36° x 45° – 52mm (Lower) ZN40 Zinc Coated, Crown Race: 28.6mm x 36° Integrated (Upper) and 40mm x 36° Press Fit (Lower) |
| Stem |
Evil 12 Gauge, Clamp: 35mm, Length: 45mm |
| Handlebar |
Evil Enerygy Bar, UD Carbon, Rise: 35mm, Clamp: 35mm, Width: 780-810mm, Backsweep: 8˚, Upsweep: 5˚ |
| Saddle |
WTB Volt Medium, Width: 142mm, Chromoly Saddle |
| Seatpost |
Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 185mm |
| Grips |
Evil Palmela Handerson lock-on |
| Rear Derailleur |
Shimano XT RD-M8100 |
|---|---|
| Crank |
Shimano XT FC-M8150, 170mm |
| Shifters |
Shimano XT SL-M8100-R, I-Spec |
| Cassette |
Shimano XT CS-M8100-12, 10-51T |
| Chain |
Shimano XT CN-M8100, 118 Links |
| Brakes |
Hydraulic Disc |
| Rims |
166mm |
|---|---|
| Tires |
Front: Maxxis Minion DHF EXO TR, 29×2.5 WT, Rear: Maxxis Minion DHF EXO TR, 29×2.5 WT |
| Motor |
Shimano DU-EP800 |
|---|---|
| Battery |
Shimano BT-E8036, 630Wh |
| Remote |
Shimano SC-EM800 |
| Charger |
Shimano Charger EC-8004-2 (USA/Canada) |
