2021 Commencal Meta HT AM Ride Bike
Product
Commencal Meta HT AM Ride Bike
Model Year
2021
Riding Type
Trail
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
27.5″ (650b)
Frame Material
Aluminum
Frame Material Details
6066 T6 alloy, molded chainstay and seatstay protection
Rear Travel
Hardtail
Rear Shock
N/A
Fork
RockShox 35 Gold RL, DebonAir spring, rebound adjust, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125″ top, 1.5″ bottom
Headset
ACROS, alloy cups, ZS44/ZS56, sealed bearings
Stem
RIDE ALPHA Freeride 40, 31.8mm bar clamp, 40mm length
Grips
RIDE ALPHA DH, ultra-soft compound, single lock-on
Brakes
SRAM Level, 2-piston, SRAM G2 CleanSweep 6-bolt rotors (200mm front, 180mm rear)
Brake Levers
SRAM Level
Drivetrain
1x
Shifters
SRAM SX Eagle, 12-speed
Front Derailleur
N/A
Rear Derailleur
SRAM SX Eagle, 12-speed
ISCG Tabs
No
Chainguide
N/A
Cranks
SRAM X1 1000 Eagle DUB, 170mm length
Chainrings
SRAM X1 1000 Eagle, 32 tooth, narrow/wide
Bottom Bracket
SRAM DUB, 68mm BSA threaded
Pedals
N/A
Chain
SRAM NX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Rims
e*thirteen LG1 EN Base, 32 hole, 35mm inner width
Hubs
Front: Formula DC-711, 32 hole, sealed bearings, 6-bolt rotor mount, 15x110mm Boost
Rear: Formula DC-348A, 32 hole, sealed bearings, 6-bolt rotor mount, 12x148mm Boost, HG driver
Rear: Formula DC-348A, 32 hole, sealed bearings, 6-bolt rotor mount, 12x148mm Boost, HG driver
Spokes
Sapim Leader, J-bend, 2.0mm, stainless steel, with Nylok
Tires
VEE Tire Co. Flow Snap, MPC compound, Synthesis, tubeless ready, 27.5″ x 2.6″
Saddle
Fabric Scoop Flat Sport, steel rails
Seatpost
RIDE ALPHA, 400mm length (SM/MD), 450mm length (LG/XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
12x148mm Boost
Max. Tire Size
29″: 60mm (2.35″)
27.5″: 71mm (2.8″)
27.5″: 71mm (2.8″)
Bottle Cage Mounts
Yes (single)
Colors
Sand, Dirt
Warranty
5 years frame; 2 years Commencal/RIDE ALPHA components; 6 months paint/decals
Weight
30 lb 13.8 oz (14,000 g)
