Enhanced Fork Stability and Jump Performance
Sur Ron Electric Bikes: Where Power Meets Passion
-
INSTANT POWER
The EIC system is built, developed and tested by Sur-Ron in their state-of-the-art headquarters using only the best available tech and materials. Sine wave controllers deliver smoother power, more torque and ReGen for improved range. Running on a primary drive belt set up the Sur Ron provides instant power, smoothly.
-
BATTERY TECHNOLOGY
Introducing the Surron 60V 40Ah Battery, a state-of-the-art lithium-ion powerhouse designed to revolutionise your riding experience. Crafted by Sun-Ron, this cutting-edge battery charger delivers reliable and consistent charging for your Li-ion pack within a mere 3 hours. The 10A fast recharge ensures your Surron is ready to hit the trails in no time. With a 67.2 VDC output, this charger guarantees efficient performance.
Charge Anywhere, Anytime:
Whether you prefer charging the battery in the bike or detaching it within 15 seconds for charging away from the bike, the Surron 60V 40Ah Battery provides ultimate flexibility. Emitting low noise, this charger ensures a full charging time of 3 hours at any domestic plug, making it a hassle-free charging solution.
-
HIGH GRADE MOTOR DESIGN
High power permanent magnet synchronous motor is an excellent product which is based on electromagnetic simulation and magnetic circuit structure optimization design and combines with rich experience in engineering design. With high-performance permanent magnet element, solid material, exquisite technology, the motor has high power density, high-temperature resistance grade, high motor speed, wide efficient platform and large output torque
Technical SPECIFICATIONS
Motor Type
PMSM
Mounting Position
Mid Weight / Motor External
Diameter
7.0kg / 180mm
Motor Axial Length
130mm
Peak Efficiency
95.60%
Cooling Method
Air-Cooled
Controller Controller Type
X Version Sine Wave
Dimensions
240mm x 110mm x 50mm
Peak Efficiency
98.50%
Power Modes
Eco and Sport Motor Power System
Rated Voltage
Rated Power / Peak Power
3000W / 6000W
Rated Torque / Peak Torque
10.2Nm / 39.00Nm
Motor Shaft Output Torque
1000RPM: 35.40Nm
Rated Rotation Speed
4300RPM
Peak Efficiency
97.8%
Range of Efficiency (≥80)
1.4Nm – 21.5Nm
Chassis
Swing Arm Material: No. 6061 T4 & T6 Aluminium Alloy
Gear Ratio
1:7.6
Transmission
Primary Belt & 420 Drive Chain
Belt Brand & Model
German Continental Brand, 8M CXA
Horn
European Standard Horn
Battery
60V 40A Lithium Battery with 176 Panasonic Cells
Battery Life Time
500 Cycles (and then the capacity reduces step by step)
Battery Charge Level
Integrated Battery LCD Display
Charger
10A
Charing Time
2.5-3.5 Hours
USB Connection
USB-2.1 A Single Socket
Speedometer
LCD Digital Speedometer
LED Headlight & Rear Light
Yes
Crate Dimension
1650mm x 850mm x 310mm
Gross Weight
70kg
To Assemble from Crate
